##### 수정로그 #####
2021.11.25 김현중 신규
*/
//**************************************** GLOBAL ********************************************//
// widget
var layout;
var graph_obj = function(){
this.temp_graph; // temperature
this.humi_graph; // humidity
this.elec_graph; // electronic
this.co2_graph; // carbon dioxide
this.aero_graph; // aerosol (air polution)
this.cnt_graph; // count
};
var graph_box = new graph_obj();
// data
var data_obj = function(){
this.temp_dat; // temperature
this.humi_data; // humidity
this.elec_data; // electronic
this.co2_data; // carbon dioxide
this.aero_data; // aerosol (air polution)
this.cnt_data; // count
}
//*************************************** EXECUTION ******************************************//
$(() => {
//<<<<<<<<<<<< CREATE WIDGET >>>>>>>>>>>>>>
//layout
layout = create_layout();
//graph
graph_box.temp_graph = create_graph('온도(℃)', '#FF4500', 100, 0);
graph_box.humi_graph = create_graph('습도(%)', '#1E90FF', 100, 0);
graph_box.elec_graph = create_graph('전력(KW)', '#DAA520', 10, 0);
graph_box.co2_graph = create_graph('CO2(ppm)', '#DCDCDC', 800, 0);
graph_box.aero_graph = create_graph('미세먼지(㎍)', '#FFE4E1', 100, 0);
graph_box.cnt_graph = create_graph('개수(EA)', '#9ACD32', 1000, 0);
layout.getCell('temp_third').attach(graph_box.temp_graph);
layout.getCell('humi_third').attach(graph_box.humi_graph);
layout.getCell('elec_third').attach(graph_box.elec_graph);
layout.getCell('co2_third').attach(graph_box.co2_graph);
layout.getCell('aero_third').attach(graph_box.aero_graph);
layout.getCell('cnt_third').attach(graph_box.cnt_graph);
select_data('TE0001', 'temp', 1000, '온도(℃)', 5);
select_data('HU0001', 'humi', 1000, '습도(%)', 5);
select_data('CE0001', 'elec', 1000, '전력(KW)', 5);
select_data('CO20001', 'co2', 1000, 'CO2(ppm)', 5);
select_data('FD0001', 'aero', 1000, '미세먼지(㎍)', 5);
select_data('CNT0001', 'cnt', 1000, '개수(EA)', 5);
});
//*************************************** CONFIG & LOGIC ******************************************//
//LAYOUT [Main] (5*2)
function create_layout(){
return new dhx.Layout("layout", { //LAYOUT
rows: [
{
padding:'15px',
type: "wide",
cols: [
{
width: "33%",
rows: [
{
height:"33%",
header: "온 도",
id: "temp_first",
html: `<div>
<i style = "color:#FF0000" class="xi-factory xi-5x"><\/i>
<i style = "color:#FF0000" class="xi-thermometer xi-3x"></i>
<span id ="temp" class= "number">0</span>
<\/div>`
},
{
height:"63%",
id: "temp_third",
html: "세팅시간(분) : 0"
},
]
},
{
width: "33%",
rows: [
{
height:"33%",
header: "습 도",
id: "humi_first",
html: `<div>
<i style = "color:#4169E1" class="xi-factory xi-5x"><\/i><i style = "color:#4169E1" class="xi-tint xi-3x"></i>
<span id ="humi" class= "number">0</span>
<\/div>`
},
{
height:"63%",
id: "humi_third",
html: "세팅시간(분) : 0"
},
]
},
{
width: "33%",
rows: [
{
height: "33%",
header: "전 류",
id: "elec_first",
html: `<div>
<i style = "color:#FF9614" class="xi-warning xi-5x"><\/i><i style = "color:#FF9614" class="xi-flash xi-3x"></i>
<span id ="elec" class= "number">0</span>
<\/div>`
},
{
height:"63%",
id: "elec_third",
html: "세팅시간(분) : 0"
},
]
},
]
},
{
padding:'15px',
type: "wide",
cols: [
{
width: "33%",
rows: [
{
height: "33%",
header: "이 산 화 탄 소",
id: "co2_first",
html: `<div>
<i style = "color:#778899" class="xi-cloud xi-5x"><\/i><i style = "color:#778899" class="xi-tornado xi-3x"></i>
<span id ="co2" class= "number">0</span>
<\/div>`
},
{
height:"63%",
id: "co2_third",
html: "세팅시간(분) : 0"
},
]
},
{
width: "33%",
rows: [
{
height: "33%",
header: "미 세 먼 지",
id: "aero_first",
html: `<div>
<i style = "color:#6A5ACD" class="xi-foggy xi-5x"><\/i><i style = "color:#6A5ACD" class="xi-blackberry xi-3x"></i>
<span id ="aero" class= "number">0</span>
<\/div>`
},
{
height:"63%",
id: "aero_third",
html: "세팅시간(분) : 0"
},
]
},
{
width: "33%",
rows: [
{
height: "33%",
header: "수 량",
id: "cnt_first",
html: `<div>
<i style = "color:#6B8E23" class="xi-apps xi-5x"><\/i><i style = "color:#6B8E23" class="xi-plus-circle xi-3x"></i>
<span id ="cnt" class= "number">0</span>
<\/div>`
},
{
height:"63%",
id: "cnt_third",
html: "세팅시간(분) : 0"
},
]
},
]
},
]
});
}
//GRAPH [spline]
function create_graph(name, color, max, min){
return new dhx.Chart("", {
type: "splineArea",
scales: {
"bottom": {
text: "seconds"
},
"left": {
maxTicks: 5,
max: max,
min: min
}
},
series: [
{
id: "main_idx",
value: name,
color: color
},
],
legend: {
series: ["main_idx"],
halign: "right",
valign: "top"
},
});
}
//*************************************** FUNCTION [QUERY] ******************************************//
function select_data(code, name, delay, unit, max_length){
var span_node = name + 'first';
var data_arr = new Array();
data_arr.push({'seconds' : now_now(), [unit] : Number(0)})
setInterval(function(){
select_async('',[{
'table':'denex_test',
'column' : ['value'],
'order' : {'reg_time':'desc'},
'limit' : [0,1],
'where':{and:[{column : 'code', 'type' : '=', 'data' : code}]}
}]
).then((result_data)=>{
result_data = result_data.data[Object.keys(result_data.data)[0]];
$(`#${name}`).text(result_data[0].value);
if(data_arr.length > max_length){
data_arr.shift();
}
data_arr.push({'seconds' : now_now(), [unit] : Number(result_data[0].value)})
graph_box[name+'_graph'].data.parse(data_arr);
});
}, delay);
}
//now seconds
function now_now(){
var now_today = new Date();
var now_hours = now_today.getHours();
var now_minutes = now_today.getMinutes() < 10 ? '0'+now_today.getMinutes() : now_today.getMinutes();
var now_seconds = now_today.getSeconds() < 10 ? '0'+now_today.getSeconds() : now_today.getSeconds();
return `${now_hours} : ${now_minutes} : ${now_seconds}`
}
